Domestically developed and independently researched
The CCUSR8116, a RAID card which serves as the host bus adapter, is developed domestically and independently . The card leverags the front-to-back collaboration of PCIe 3.0 x8 host interfaces with 16 dedicated 6Gb/s SATA channels providing superior transmission bandwidth for up to 40 hard drives.
Built on a professional-grade domestic RoC chip, the C*CORE-RAID adapter integrates mature accumulated technologies by our team over many years in the storage field. As a result, it is an ideal partner for cost-effective, high-performance, and large-capacity storage applications involving SATA hard drives.
Excellent Transmission Bandwidth of PCIe Gen3
CCORE-RAID The C*CORE-RAID host bus adapter enables customers to fully leverage the transmission capabilities of PCIe 3.0, featuring 8 PCIe channels, each capable of supporting up to 8Gb/s transfer speeds. With a RAID5 configuration of multiple SATA hard drives, it achieves a sustained transmission performance of up to 2500MB/s!
Professional RAID solution
The C*CORE-RAID host bus adapter represents a professional-grade RAID solution, drawing on the team's extensive experience in RAID and storage technology to deliver high-performance, cost-effective RAID storage to users. The adapter's implementation is founded on our RAID technology that has been thoroughly tested and validated by professional users over many years. With 16 dedicated 6Gb/s SATA channels, it supports hard drives of different format (including 512, 512e, and 4Kn) and enables high-performance RAID0, 1, 5, 6, 10, 50, and JBOD configurations.
The C*CORE-RAID adapter aims to maximize the uptime and accessibility of RAID storage. Its advanced RAID programs enhance the ability to recover data from failed drives and optimize the rebuild process. The RAID GUI management interface provides monitoring and maintenance capabilities, enabling administrators to digest the status of each RAID storage configuration and easily schedule required verification tasks.
Seamless Upgrade for RAID Storage
The C*CORE-RAID host bus adapter offers exceptional flexibility in storage configuration, enabling customers to freely expand or convert RAID storage configurations to meet the evolving demands of storage applications without compromising existing data.
Online Capacity Expansion (OCE) allows administrators to add new drives to existing arrays, thereby expanding available capacity. Online RAID Level Migration (ORLM) enables administrators to convert from one RAID level to another, allowing them to adjust storage configurations for optimal performance or data security.
Customized RAID Solution Services
The C*CORE-RAID platform provides customized solution services to enterprise customers, fulfilling the requirements of customer-defined storage applications across Linux and Windows platforms, and is ready to offer white-label services to solution providers. With complete application interfaces available for integration projects, we also offer various cabinet management application interface services, including SGPIO and I2C.
| Models | CCUSR7116 (HBA Card) | CCUSR8116 (RAID Card) |
| Functional Specifications | ||
| Host Interface | x8 PCIe Gen 3.0（8Gb/s） | x8 PCIe Gen 3.0 （8Gb/s） |
| Disk Interface | x16 SATA3.0（6Gb/s） | x16 SATA3.0（6Gb/s） |
| Port Quantity | 16 | 16 |
| Port Type | x4 SFF-8643 mini SASHD | x4 SFF-8643 mini SASHD |
| Cache | None | 2GB DDR |
| Cache Protection | None | EMMC Flash Storage |
| RAID Modes | 0/1/5/6/10/50/60/JBOD | 0/1/5/6/10/50/60/JBOD |
| Maximum Power | 8 Watts | 9 Watts |
| Dimensions | Standard Half-HeightPCIe Card | Standard Half-HeightPCIe Card |
| AdvancedRAID Features | ||
| BIOS Upgrade Flash ROM | Yes | Yes |
| Bad Sector Detection and Repair | Yes | Yes |
| BIOS UEFI(HII） | Yes | Yes |
| BootableRAID Arrays | Yes | Yes |
| Support for MultipleRAID Partitions | Yes | Yes |
| Online Array Roaming | Yes | Yes |
| OnlineRAID Level Migration | Yes | Yes |
| Online Capacity Expansion | Yes | Yes |
| Automatic Array Rebuilding | Yes | Yes |
| Automatic Disk Insertion and Ejection Detection | Yes | Yes |
| Hot Spare | Yes | Yes |
| Task Management (Array Check Scheduling) | Yes | Yes |
| RAID Monitoring and Management Suite | ||
| Cabinet Management Interface | I2C | SGPIO/I2C/IO |
| Web-Based Array Management Software | Yes | Yes |
| Email Notifications | Yes | Yes |
| S.M.A.R.T | Yes | Yes |
| Event Logging | Yes | Yes |
| Host Platform and Operating System | ||
| Host Platforms | Loongson/Feiteng/Shenwei/Hygon/Zhaoxin/Kunpeng | Loongson/Feiteng/Shenwei/Hygon/Zhaoxin/Kunpeng |
| BIOS | UEFI(HII） | UEFI(HII） |
| Operating Systems | Galaxy Kylin/Zhongbiao Kylin/Loongson/UOS/Windows/Linux | Galaxy Kylin/Zhongbiao Kylin/Loongson/UOS/Windows/Linux |
| Operating Environment | ||
| Operating Temperature | +5℃ ～ +85℃ | +5℃ ～ +85℃ |
| Storage Temperature | -20℃ ～ +105℃ | -20℃ ～ +105℃ |
| Operating Voltage | PCIe: 12V, 3.3V | PCIe: 12V, 3.3V |
? High-performance PCIe 3.0 x8 host interface
? Supporting RAID 5, 6, and RAID50 storage solutions
? Supporting up to 40 SATA SSDs with a total storage capacity of 256TB
? Offering customized solution services
? Various types of storage servers
? Web servers
? NAS servers
? Various monitoring servers
? 16 internal SATA channels with a capacity of 6Gb/s, scalable to support up to 40 SATA hard drives
? Supporting RAID 0, 1, 5, 6, 10, 50, and JBOD
? Fast array setup capabilities
? Robust RAID monitoring and management capabilities
? Compatible with a wide range of operating system platforms
